Quick Answer: Flow meter types split by measuring principle: Coriolis mass, electromagnetic, ultrasonic, vortex, oval gear, and thermal mass. Flow transmitters convert sensor output into 4-20 mA HART, pulse, or RS485 Modbus signals for PLC or DCS systems. The right choice depends on fluid, pipe size, temperature, pressure, conductivity, and target flow range.
Most engineers skip this part. But the difference matters. A flow meter is the primary sensing element. A flow transmitter is the electronics that read the sensor and send a standard signal. Many devices combine both in one body. The flow transmitter may be integral or remote. On customer sites in Southeast Asia and the Middle East, remote versions are common for high temperature or vibration.
Electromagnetic flow meters work for conductive liquids. Water, wastewater, acid, caustic, slurry, and pulp are typical. The liquid needs a minimum conductivity of 5 µS/cm. Pure oils and deionized water will not work. Silver Automation Instruments supplies electromagnetic flow meters from DN15 up to DN2000. Accuracy is 0.5 percent of reading. Liners include PTFE, hard rubber, and polyurethane. Electrodes are 316L, Hastelloy, titanium, or tantalum. Last year a customer in Vietnam asked us for a seawater flow meter for a desalination plant. We supplied an electromagnetic meter with PTFE liner and titanium electrodes. The meter sent 4-20 mA HART output to a PLC.
In practice, this type is the first choice for water and wastewater because there is no pressure drop and no moving parts. Bidirectional measurement works well. Use it for dosing, raw water intake, effluent discharge, and custody transfer where local standards allow.
Coriolis mass flow meters measure mass flow directly. They also measure density and temperature. This type works for oils, syrups, chemicals, liquefied gas, molasses, and dairy products. Accuracy can reach 0.1 percent of rate. Silver Automation Instruments offers Coriolis mass flow meters from DN3 to DN200. A food processor in Indonesia batches palm oil and glucose with a DN25 Coriolis meter. The unit measures kg/h and sends pulse output to a PLC. No separate temperature compensation is needed for mass flow.
Cost is higher than other types. But the meter handles viscosity changes and high pressure. It also detects gas bubbles in liquid. For batching and filling, this meter reduces overfill and raw material waste.
Ultrasonic flow meters come in clamp-on and inline versions. The clamp-on type suits large pipes, temporary flow surveys, and lines that cannot be shut down. It is common in HVAC chilled water, seawater, fire water, and river water pumping. A contractor in the Philippines used a clamp-on ultrasonic flow meter on a DN600 cooling water line. Installation took one afternoon. The meter sent 4-20 mA and RS485 data to a building management system.
Inline ultrasonic meters give better accuracy for clean liquids. Use them for custody transfer, district heating, and chemical transfer. The meter has no moving parts and low pressure drop. For wastewater with high solids, check the signal quality first.
Vortex flow meters work for steam, compressed air, hot gas, and some clean liquids. They need a Reynolds number above 10,000. Vibration can disturb the signal. In steam lines, vortex meters are often cheaper than Coriolis. Silver Automation Instruments supplies vortex flow meters for saturated steam up to 250°C and 25 bar. A food plant in Malaysia used a DN80 vortex meter on a steam header. The output was compensated in the PLC for pressure and temperature.
Use this type for boiler steam, air compressor output, natural gas, and solvent recovery. The meter has no moving parts but requires straight pipe upstream and downstream.
Oval gear flow meters are positive displacement devices. They handle diesel, fuel oil, lube oil, heavy fuel oil, resin, and high viscosity liquids. Accuracy is 0.5 percent or 0.2 percent. Silver Automation Instruments offers oval gear flow meters from DN4 to DN100. A paint manufacturer in Southeast Asia uses Silver Instruments oval gear flow meters on resin and solvent batching lines. The meter gives pulse output to a batch controller.
Because this meter traps a fixed volume between gears, it measures very low flow rates well. It is common for marine fuel bunkering and truck loading. Install a strainer upstream. For dirty liquids, add a filter.
Thermal mass flow meters measure gas mass flow directly. Use them for compressed air, biogas, natural gas, aeration air, and stack gas. They do not need pressure and temperature compensation. Insertion types are popular for large ducts. Inline types suit small pipe sizes. A wastewater plant in Thailand used insertion thermal mass flow meters on aeration blowers. The meters sent 4-20 mA signals to the SCADA system.
Silver Automation Instruments provides thermal mass flow meters for pipe sizes from DN15 to DN300 inline and larger for insertion. Gas type, pressure, and temperature must be specified before calibration.
A flow transmitter converts the sensor signal to a standard output. Common outputs are 4-20 mA HART, pulse, RS485 Modbus, and Profibus. Most Silver Automation Instruments flow meters can be ordered with integral display or blind remote electronics. For ATEX Zone 1 areas, specify Ex d or Ex ia protection.
We have seen this issue on customer sites many times. A meter with pulse output may need a separate totalizer in the control panel. Pressure transmitters and paperless recorders often sit next to flow meters. A pressure transmitter gives density or energy compensation for gas and steam. A paperless recorder logs flow, pressure, and temperature trends. We supply both as part of a metering skid.
Send us your fluid, pressure in bar, temperature in °C, pipe size in DN, and flow range. Tell us the installation type and signal output. For electromagnetic meters, include conductivity in µS/cm. For gas meters, include gas composition. Contact Silver Automation Instruments at Tel: +86-25-68650347, WhatsApp: +86-25-52155837, WeChat: +86 15365082610. Our team serves Southeast Asia, Oceania, Latin America, Africa, and the Middle East.
What is the difference between a flow meter and a flow transmitter? A flow meter is the sensing element. A flow transmitter reads that sensor and sends a standard signal such as 4-20 mA HART. Many industrial devices combine both in one housing.
Which flow meter is best for low conductivity water? For demineralized or deionized water, avoid electromagnetic meters because conductivity is below 5 µS/cm. Use an ultrasonic flow meter or a vortex flow meter if flow conditions allow.
Can a Coriolis mass flow meter measure viscous food fluids? Yes. Coriolis meters handle honey, syrup, palm oil, and dairy fluids. They measure mass directly and are not affected by viscosity changes.
What output should I choose for a PLC? 4-20 mA HART is the most common. RS485 Modbus gives more data points and works well for multi-variable instruments. Pulse output suits batching and totalizing.
How do I get a price for a flow meter? Send your fluid, pipe size, pressure, temperature, and flow range to Silver Automation Instruments. Include signal output and any hazardous area certification. We will reply with a quotation.
